14.6V 100ah lifepo4 battery lithium cell for Camping Daly BMS
14.6V 100ah lifepo4 battery lithium cell for Camping Daly BM |
| Nominal Capacity | 100.0Ah |
| Nominal Voltage | 12.8V |
| Internal Impedance | ≤20mΩ |
| Standard Charging | 20A 0.2C |
| Charging Voltage | 14.6V |
| Max. Continuous Charge Current | 50.0A |
| Peak discharging | 2C 200A(<3S) |
| Max Continuous Discharge Current | 100A |
| Cycle Life | >2000 Cycles @ 0.2C Charge/Discharge at
100%DOD,End of Life 70% Capacity. |
| Operating Temperature | Charge:0℃~ 60℃ |
| Discharge:-20℃~ 60℃ |
| Weight | Approx. 11.5Kg |
| Size | 332*176*220mm |
| Power Consumption | Low power consumption mode | ≤100μA |
| Over charge Protection | Over charge detection voltage | 3.75V |
| Over charge release voltage | 3.38V |
| Over discharge protection | Over discharge detection voltage | 2.2V |
| Over discharge release voltage | 2.7V |
| Over current protection | Charging overcurrent detection current (detection time) | 50A (1S) |
| Discharging overcurrent detection current 1(detection time) | 100A (1S) |
| Discharging overcurrent detection current 2(detection time) | ≥200A(100ms) |
| Temp. Protection | Detection temperature | 65±2℃ |
Application:
Motorhome,Caravan,boat,camping,RV,Solar energy
About the Transportation&Delivery
1. Shippment to USA:By sea+Express(DDP,Tax free)
ETD:5-8 days
ETA:25-35 days after sailing(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be updated after pick up by local express.Usually it will take around 15-25 days after sailing.
2. Shipment to EU:By railway+Express(DDP,Tax free).Except Switzerland,Romania
ETD:5-8 days
ETA:30-45 working days after shipping(This is the delivery time for most orders. Please wait patiently or contact us online)
The tracking will be updated after pick up by local express.Usually it will take around 25-40 working days after shipping.
3. We can't deliver the following address directly:
USA: Military address and PO box address are not acceptable;
Puerto Rico, Virgin Islands, Guam, Alaska Note: Hawaii does not include customs duties and requires additional freight, Please contact us online.
Portugal: Azores and Madeira
Spain:Canary Islands, hueda and melilia
Russia: Kamchatka Peninsula
Other:Some remote areas not listed,Please provide shipping address and zip code to to us to check.
